Operating voltage: 110…265 VAC/DC
Control outputs for closing coils: 3
Control outputs for opening coils: 6
Main and PIR contacts: 9 × 2
Coil current: 3 × 3 (I/O)
Coil / motor / station voltage: 6
Motor current via shunt: 3
Sensor (+/−10 V / 0…20 mA): 6 / 2
Sensor digital: 3 × 4
Analog control outputs (0…10 VDC): 4
Reference voltage for sensors (10 VDC / 200 mA): 2
PC connection: 1 × Ethernet
Interfaces: RS422 (no control of additional devices possible)
Interfaces for external devices: 3 × RJ45 for PROMET and voltage sources, 1 × RJ45 for CSW3
Housing: 19" drawer housing
Protection: IP20
Dimensions: 482.6 × 265.9 × 242.0 mm
Weight: 7.3 kg
