Operating voltage: 110–265 VAC/DC
Control outputs for closing coils: 1
Control outputs for opening coils: 2
Main and PIR contacts: 3 × 2
Coil current: 1 × 2 (I/O) + 1 × O
Coil / Motor / Station voltage: 1
Motor current via shunt: 1
Sensor (+/−10 V / digital): 3
Sensor (+/−10 V / 0–20 mA): 1
Auxiliary contacts: 2 × 4
Reference voltage for sensors (10 VDC / 200 mA): 1
Relay control outputs: 1
PC connection: 1 × Ethernet
Interfaces: 1 × USB A, 1 × USB B
Interfaces for external devices: 3 × RJ45 for external devices, 1 × RJ45 for CSW3
User interface: 7" graphical display with touch screen and 2 function keys
Housing: Robust hard shell case
Protection class: IP65 (closed)
Dimensions: 424 × 340 × 173 mm
Weight: 5.3 kg
