Volume: 16.8m³
Interior Dimensions: (WxHxD): 3000x2100x4300mm
Exterior Dimensions: (WxHxD) 5050x2350x2250mm
Safety device (standard):
No fuse breaker, over pressure, over heat and over current protection for compressor
Over temp. protect, over load protect of blower, dry heat protection
Standard accessories: Sight window*1,cable port(portΦ50mm)*1,chamber lamp*1, status indicator
Control System: Balanced Temperature & Humidity Control System
Refrigeration system:
Water Cooled
Semi-Hermetic compressor, cascade stage refrigeration system
CFC-Free refrigerant (HFC-507/HFC-23)
Controller:
Panel:7-inch LCD Touch panel, Chinese or English display selectable
Operation model: Program or fix point running
Memory capacity: 120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles
Accuracy: Temp.:0.1% of F.S±1 digit ; Humidity:0.1% of F.S±1 digit
Input: Temp.:pt-100, Humidity: pt-100 or ~5V DCV
Comm.port: RS-232 or RS-485
Temp. range: Maximum:80ºC,120ºC;Minimum:-60ºC,-50ºC,-40ºC,-30ºC,-20ºC,-10ºC,0ºC
Humidity Range: 10%,20%,30%~95%
Temp. constancy: ±0.5ºC
Humidity constancy: ±2.5%R.H
Temp. uniformity: ±2.0ºC
Humidity uniformity: ±5.0%R.H
Ambient Temp.: +5ºC~+35ºC
Wiring method: AC 380±10%50Hz,3 phase 4 wires +Ground Wires
Heat up time: +20ºC~+80ºC, Within 60 min
Pull down time: +20ºC~-55ºC\ -40ºC\-20ºC\-10ºC ,Within 120 or 90 or 60 min
Interior material: Stainless Steel Plate(SUS 304)
Exterior material: Baked Painting Steel Or Stainless steel(SUS304)
Insulation material: Rigid polyurethane foam
Door size (mm): Single wing:W800*H1800;Double wing:W1600*H1800;
