Color: Gray
Pitch: 1.02 mm
Gender: Jack (Female)
Shielding: Unshielded
USOC Codes: RJ11, RJ12, RJ14, RJ25
Configuration: 1x1
Tab Direction: Tab Up
Current Rating: 1.5 A
Mounting Angle: Right Angle
Mounting Style: Through Hole
Voltage Rating: 125 VDC
Contact Plating: Gold
Number of Ports: 1 Port
Contact Material: Phosphor Bronze
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 6 Position
Insulation Resistance: 500 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Number of Positions / Contacts per Port: 6P6C
