Gain: 4.8 dBi
VSWR: 2.0:1
Style: T-Bar Flex
Width: 8 mm
Height: 0.4 mm
Length: 22 mm
Impedance: 50 Ohms
Cable Type: 100 mm RF1.13
Application: Embedded Design, POS, Headsets, Tablets, Gateway, Access Point, Handheld, Telematics, Tracking, Healthcare, M2M, Smart Grid, OBD-II
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Embedded
Number of Bands: 1 Band
Center Frequency: 5.4875 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.825 GHz
Minimum Frequency: 5.15 GHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
