Gain: 2.8 dBi, 3.1 dBi, 2.7 dBi
VSWR: 1.8:1, 1.5:1, 2.0:1
Style: I-Bar
Width: 30.1 mm
Height: 6.7 mm
Length: 105.1 mm
IP Rating: IPX7
Impedance: 50 Ohms
Cable Type: 1 M RG174
Application: Remote Monitoring, POS, Gateway, Telematics, Tracking, Healthcare, M2M, Smart Grid, Logistics, Energy, Retail
Mounting Style: Adhesive Mount
Number of Bands: 3 Band
Center Frequency: 1.61 GHz, 1.94 GHz, 3.55 GHz
Mechanical Style: Module
Maximum Frequency: 2.69 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
