Gain: 1.8 dBi, 4.0 dBi
Width: 9.35 mm
Height: 84 mm
Length: 84.0 mm
Diameter: 9.35 mm
Bandwidth: 85 MHz, 700 MHz
Impedance: 50 Ohms
Cable Type: RP-SMA Male
Technology: WiFi / Bluetooth / WLAN / BLE / ZIGBEE
Application: Embedded Design, Gateway, Access Point, Handheld, Telematics, Tracking, Healthcare, M2M, Smart Grid, OBD-II
Polarization: Vertical
Mounting Style: Screw Mount
Frequency Range: 2400-2485 MHz / 5150-5850 MHz
Number of Bands: 2 Band
Center Frequency: 2.44 GHz, 5.455 GHz
Mechanical Style: Whip
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: WiFi, WLAN
Maximum Operating Temperature: + 120 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
