Table size(mm): 1500*1500
Payload(kg): 1000
Wave form: Half sine pulse
Acceleration range(G): 5-60
Pluse duration(ms): 6-18
Bump repetition frequency: 1-80
Drop height range: 5-180mm
Max velocity variation: 2.8m/s
Machine dimension(mm): 1600*1650*1200
Machine weight(kg): 6500
Power & Air supply: AC220V ±10% 50Hz Air supply:8kg 23m3 gasholder
Standards: GB/T2423.4,GB/T2423.6, IEC68-2-29, JJG497-2000, JISC0042-1995 etc
*Product image is for illustrative purposes only
Components and other electronic and electrical products may experience repeating impact during transportation or use. Bump test can be used as a method to ensure the design structure is satisfying or as a quality assurance method. Specimen will experience regular peak acceleration and continuous impact with standard pulse during the bump test.
