TABLE DIMENSIONS
Side to Side: 37.4 in. (95 cm)
Front to Back : 45.3 in. (115 cm)
TEST CAPABILITIES
Max. Acceleration: 1.000g
Min. Pulse Duration: 2 msec (half sine)
Max. Velocity Change :
Free Fall: 20 – 25 ft./sec (6.1 – 7.6 m/sec)
Accelerated: 25 – 50 ft./sec (7.6 – 15.2 m/sec)
Pulse Waveforms : Half Sine; Trapezoidal*; Terminal Peak Sawtooth* (*with Optional Programmers )
MAXIMUM PAYLOAD:
Free Fall: 2,500 lbs. (1,134 kg)
Accelerated: 1,000 lbs. (454 kg)
MACHINE ENVELOPE DIMENSIONS
Height: 128 – 208 in. (325 – 532 cm)
Side to Side: 79 in. (201 cm)
Front to Back: 56 in. (142 cm)
POWER REQUIREMENTS
Machine :200 – 240 VAC/3Φ/50 – 60 Hz: 8 amp min.; 380 – 480 VAC/3Φ/50 – 60 Hz: 4 amp min.
Controller: 100 – 120 VAC/1Φ/50 – 60 Hz: 3 amp min; 200 – 240 VAC/1Φ/50 – 60 Hz: 3 amp min.
PNEUMATIC REQUIREMENTS
Nitrogen: 2.200 psi (150 bar)
