Specification:
Maximum force: 50KN
Machine type: Benchtop
Grade: 0.5
Measuring range of force: 0.4%~100%FS
Accuracy: ±0.5%
Resolution of force: 1/500000 of maximum force
Resolution of displacement: 0.001mm，Accuracy：≤±0.5%
Speed range of crosshead: 0.01~500mm/min (Max 1000mm/min ordered)
Valid tension space: 750mm
Valid compression space: 1000mm
Sample thickness: Flat jaw: 0-14 Round jaw: φ4～φ14
Power supply: 1P,220V±10%,50/60Hz
Working condition: RT 10~40℃，relative humidity≦90%
Dimension of host machine: 800×620×1830 mm 350Kg
Standard accessories:
1-1. Computer
1-2. Test Software
1-3. Printer
1-4. Celtron Load Cell
1-5. Panasonic Servo motor
1-6. Controller
1-7. Remote controller
1-8. OMRON Encoder
1-9. Wedge tensile fixture
Flat jaw: 0-14mm
Round jaw: φ4～φ14mm
Clamping Width: 35mm
Depth: 40mm
1-10. Compression plates: Diameter: 100mm
1-11. Tools
Optional Accessories
2-1. Extensometer
Model: YYU-25/50
Gauge length: 50mm
Deformation: 25mm
2-1. Bending fixture
Diameter of the rollers: 10mm (customizable)
Length of the rollers: 50mm
Height of support: 50mm
Support span: Max 250mm
