LIB DIM-1000 Blowing Sand and Dust Test Chamber (1000L)

Name: LIB DIM-1000 Blowing Sand and Dust Test Chamber (1000L)
Brand: LIB

ManufacturerLIB(View more products from this manufacturer)

ModelDIM-1000

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Internal Dimension: 1000*1000*1000mm D*W*H

Overall Dimension: 3000*6100*2200mm D*W*H

Interior Volume: 1000L

Blowing Dust:

Air velocity: 1.5 -8.9m/s

Concentration of dust: 10.7±7g/ m³

Dust particles: ＜ 150μm

Blowing sand:

Air velocity: 18.0 -29.0m/s

Concentration of sand: 0.18+0.2g/m³; 1.1+0.3g/m³; 2.2+0.5g/m³

Sand particles: 149μm - 600μm, 600μm - 850μm

Controller: Programmable color LCD touch screen controller, Ethernet connection

Testing Platform Diameter: 600mm

Door Lock: Electromagnetic lock

Testing Platform Speed: 1-7 r.p.m

Dust Detector: Integrated dust detector

Exterior Material: A3 Steel Plate with protective coating

Interior Material: SUS304 stainless steel

Standard: MIL-STD- 810

Advantages

1. Highly Accurate Sand and Dust Environmental Simulation: Equipped with precision-controlled fans and integrated sensors, the chamber reproduces desert dust and sandstorm conditions with air velocities from 1.5–29 m/s and particle sizes ranging from 149 µm to 850 µm. This ensures reliable evaluation of equipment performance under real-world abrasive and particulate exposure.

2. Flexiable Test Parameters: Users can program airflow speed, dust/sand concentration, and particle size distribution through a PID-controlled touchscreen interface. Up to 120 test profiles can be stored and recalled, allowing

repeatable testing for multiple product types without recalibration.

3. Durable, Industrial-Grade Construction: The chamber interior is made of SUS304 stainless steel, while the exterior features A3 steel with protective coating. This robust design resists wear from dust and sand, ensures long-term durability, and maintains structural integrity during continuous high-stress testing.

4. Integrated Safety and Convenience Features: An electromagnetic door lock, built-in dust detector, and large centrifugal fans provide safe, stable, and controlled testing conditions. Easy-access doors and internal fixtures simplify specimen placement, maintenance, and cleaning without compromising operator safety.

5. Versatile Application Across Industries: Ideal for military electronics, aerospace components, automotive sensors, and industrial equipment, the chamber delivers accurate performance verification against particulate ingress, abrasion, and airflow stress. Its modular design accommodates various sample sizes and test configurations, supporting diverse testing requirements.
