Gender: Plug (Pin)
Polarity: Standard
Frequency: DC to 18 GHz
Impedance: 50 Ohms
Isolation: Non-Isolated
RF Series: SMA
Body Style: Right Angle
Cable Type: RG174, RG188, RG316
Body Finish: Gold
Orientation: Right Angle
Body Material: Brass
Mating Cycles: 500 Cycles
Insertion Loss: 0.7 dB
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 335 V
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 18 GHz
Minimum Frequency: DC
Termination Style: Solder
Coupling Mechanism: Threaded
Contact Termination: Crimp
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
