Gain: 3.4 dBi
VSWR: 1.9
Style: Stubby
Length: 11 mm
Diameter: 19 mm
Bandwidth: 100 MHz
Impedance: 50 Ohms
Cable Type: 216 mm RF1.32
Wavelength: 1/2 Wave
Application: Bluetooth, WiFi, Zigbee, Thread
Unit Weight: 6.535 g
Cable Length: 216 mm
Polarization: Linear
Mounting Style: Direct / Permanent Mount
Electrical Type: Dipole
Number of Bands: 1 Band
Center Frequency: 2.45 GHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 2.5 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: MHF / U.FL
Protocol - WiFi - 802.11: WiFi
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee), 802.16
