VSWR: 1.9
Width: 13.7 mm
Height: 1.5 mm
Length: 27.94 mm
Bandwidth: 5 MHz
Impedance: 50 Ohms
Technology: Planar
Wavelength: 1/4 Wave
Application: Medical Implant Communication Service (MICS)
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 1 Band
Center Frequency: 403 MHz
Mechanical Style: Chip
Ground Plane Size: 38 mm x 84 mm
Maximum Frequency: 405 MHz
Minimum Frequency: 400 MHz
Termination Style: SMD/SMT
Protocol - Sub GHz: MICS
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
