Gain: - 8.0 dBi
VSWR: 1.9
Width: 13.7 mm
Height: 1.5 mm
Length: 27.94 mm
Bandwidth: 7 MHz
Impedance: 50 Ohms
Technology: Planar
Wavelength: 1/4 Wave
Application: Handheld Applications, Remote Controls, Pagers, Alert Devices, Portable Devices
Unit Weight: 3.382 g
For Use With: 410 MHz, LTE Band 87, LTE Band 88, Personal Mobile Radio - PMR
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 1 Band
Center Frequency: 418 MHz
Mechanical Style: Chip
Ground Plane Size: 38 mm x 84 mm
Maximum Frequency: 422 MHz
Minimum Frequency: 414 MHz
Termination Style: SMD/SMT
Maximum Operating Temperature: + 130 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM
