Gain: - 5.6 dBi
VSWR: 1.9
Style: Stubby
Length: 51 mm
Diameter: 8.5 mm
Bandwidth: 15 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: ISM, Remote Control, Alarms, Security Systems
Unit Weight: 7.193 g
Polarization: Linear
Mounting Style: Panel Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 433 MHz
Mechanical Style: Helical
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 440 MHz
Minimum Frequency: 425 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: LoRaWAN, WiFi, WLAN
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 30 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM
