Gain: 3.3 dBi
VSWR: 1.9
Style: Straight
Length: 173 mm
Diameter: 14.5 mm
Bandwidth: 70 MHz
Impedance: 50 Ohms
Cable Type: 216 mm RF1.32
Wavelength: 1/4 Wave
Application: ISM, Remote Control, Alarms, Security Systems
Unit Weight: 26.614 g
Cable Length: 216 mm
For Use With: 410 MHz, 450 MHz, LTE Band 72, LTE Band 73, LTE Band 87, LTE Band 88, Personal Mobile Radio - PMR
Polarization: Linear
Mounting Style: Direct / Permanent Mount
Electrical Type: Monopole
Number of Bands: 1 Band
Center Frequency: 433 MHz
Mechanical Style: Whip
Ground Plane Size: 102 mm x 102 mm
Maximum Frequency: 470 MHz
Minimum Frequency: 400 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: MHF / U.FL
Protocol - WiFi - 802.11: LoRaWAN, WiFi, WLAN
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM
