Gain: 5 dBi
VSWR: 1.6, 1.7, 1.8, 2, 4.7, 2.5, 2.7
Style: Yagi
Width: 20 mm
Height: 0.1 mm
Length: 120 mm
Bandwidth: 698 MHz, 803 MHz, 894 MHz, 1518 MHz, 1661 MHz, 2200 MHz, 2690 MHz, 4200 MHz, 5GHz
Impedance: 50 Ohms
Wavelength: 1/2 Wave
Application: 5G New Radio, LTE
Cable Length: 200 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Dipole
Frequency Range: 617 MHz to 5 GHz
Number of Bands: 9 Band
Mechanical Style: Blade
Maximum Frequency: 5 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Antenna Connector Type: MHF4
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: LTE-M, NBIoT
