Gain: 1.4 dBi
VSWR: 9.5
Style: Ceramic
Width: 25 mm
Height: 4 mm
Length: 25 mm
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Low Power Wide Area Applications, Remote Control, Monitoring, Sensing, Smart Home Networking, Handheld Devices
Unit Weight: 18.198 g
Polarization: RHCP
Power Rating: 8 W
Mounting Style: PCB Mount
Electrical Type: Embedded
Number of Bands: 1 Band
Center Frequency: 868 MHz
Mechanical Style: Patch
Ground Plane Size: 70 mm x 70 mm
Maximum Frequency: 876 MHz
Minimum Frequency: 863 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID
Antenna Connector Type: Pin
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
