Gain: - 12.3 dBi
VSWR: 2
Style: Stubby
Length: 12.2 mm
Diameter: 7.1 mm
Bandwidth: 26 MHz
Impedance: 50 Ohms
Wavelength: 1/4 Wave
Application: Remote Control, Monitoring, Sensing Networks
Unit Weight: 1.647 g
Polarization: Linear
Mounting Style: PCB Mount
Electrical Type: Embedded Monopole
Number of Bands: 1 Band
Center Frequency: 916 MHz
Mechanical Style: Helical
Ground Plane Size: 89 mm x 89 mm
Maximum Frequency: 928 MHz
Minimum Frequency: 902 MHz
Termination Style: Through Hole
Protocol - Sub GHz: RFID, ISM
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
