Gain: 8.5 dBi, 9.0 dBi, 9.0 dBi
VSWR: 1.5
Style: Directional
Width: 210 mm
Height: 36.5 mm
Length: 395 mm
Bandwidth: 136 MHz, 460 MHz, 80Hz
Impedance: 50 Ohms
Cable Type: 165.1 mm Coax
Wavelength: 1/2 Wave
Application: Long Distance Directional Communication
Unit Weight: 1.357 kg
Cable Length: 165 mm
Polarization: Linear
Power Rating: 100 W
Mounting Style: Bracket Mount
Number of Bands: 3 Band
Center Frequency: 892 MHz, 1.94 GHz, 2.45 GHz
Mechanical Style: Log Periodic
Maximum Frequency: 2.48 GHz
Minimum Frequency: 824 MHz
Termination Style: Connector
Protocol - Sub GHz: RFID, ISM
Antenna Connector Type: N Female
Protocol - WiFi - 802.11: LoRaWAN, Sigfox
Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE), GSM, UMTS
