Gender: Plug (Pin)
Polarity: Standard
Impedance: 50 Ohms
RF Series: MCX
Body Style: Straight
Cable Type: RG-174
Body Finish: Nickel
Orientation: Straight
Unit Weight: 1.647 g
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 500 Min
Insertion Loss: 0.1 dB max
Mounting Style: Cable Mount / Free Hanging
Contact Plating: Gold
Contact Material: Brass
Maximum Frequency: 6 GHz
Termination Style: Crimp
Contact Termination: Solder
Insulation Resistance: 1 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
