Gender: Plug (Socket)
Polarity: Reverse
Impedance: 50 Ohms
RF Series: RP-SMA
Body Style: Right Angle
Cable Type: RG-174
Body Finish: Nickel
Orientation: Right Angle
REACH - SVHC: Details
Body Material: Brass
Mating Cycles: 500 Min
Insertion Loss: 0.06 dB max
Mounting Style: Cable Mount / Free Hanging
Voltage Rating: 335 VRMS
Contact Plating: Gold
Contact Material: Beryllium Copper
Maximum Frequency: 18 GHz
Termination Style: Solder
Coupling Mechanism: Threaded
Contact Termination: Solder
Insulation Resistance: 5 GOhms
Maximum Operating Temperature: + 165 C
Minimum Operating Temperature: - 65 C
