Width: 2.9 mm
Height: 0.85 mm
Length: 4.85 mm
Approvals: UL, cUL
Tolerance: +/- 5 C
Resistance: 5 mOhms
Hold Current: 15 A
Contact Rating: 12 VDC / 25 A, 6000 cycles
Rated Temperature: + 77 C
Reset Temperature: >= + 40 C
Holding Temperature: + 25 C
Maximum Temperature: + 77 C
Maximum Leakage Current: 150 mA
Minimum Holding Voltage: 3 V
Maximum Breaking Current: 5 VDC / 80 A, 100 cycles
Maximum Operating Temperature: + 100 C
Minimum Operating Temperature: - 30 C
