Max Test Force: 200kN
Accuracy: 1 Level
Max force test range: 2%-100%
Test force relative error value: ＜±1%
Load display resolution: Max force 1/300000
Distortion measuring range: 2%-100%
Deformation relative error value: ＜±1%
Deformation of resolution: maximum deformation 1/300000
Displacement relative error value: ＜±1%
displacement resolution(mm): 0.001
Speed range: 0.005mm/min ~ 500mm/min
Tensile stroke: 600mm
Compression space: 600mm
Test width: 500mm
Grips: Tensile, compression, bending, shear, peel, tear, etc
Overall dimension: 1120*900*2500.
Servo motor power: (kW) 3
Weight: 1800kg
