Max force (kN): 600
Measure Force Range: 2%-100%
Test force relative error value: ＜ The value for ±1%
Test force resolution: Max load 1/300000
Deformation relative error value: ＜ The value for ±1%
Deformation of the resolution: The biggest deformation 1/300000
The largest tensile test space (mm): 600
Compression space (mm): 500
The piston stroke (mm): 200
Column spacing (mm): 450
Circular specimen clamping range (mm): Φ6-Φ40
The specimen thickness clamping (mm): 0-30
Flat specimen clamping width (mm): 75
The pressure plate size (mm): φ160mm
Bend the fulcrum maximum distance between two points (mm): 300
Bending roll width (mm): 140
The clamping way: Hydraulic clamping
The host dimension (mm): 840*620*2150
The oil source console size (mm): 1100*750*1000
Motor total power (kW): 2
Weight (kg): 1900
