Lonroy NDJ-5S Digital Viscometer (1～100,000mpa.s)
Manufacturer: Lonroy Model: NDJ-5S - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Widely used in grease, paint, paint, textile, food, slurry, medicine, cosmetics and other adhesives, fluid, semi fluid production industry and scientific research units.
Detailed technical parameters:
Display mode: liquid-crystal display
Speed (r/ min): 6 / 12 / 30 / 60
Rotor: 1#、2#、3#、4#
The 0# rotor is optional, for measuring ultra low viscosity below 15
Measuring range(mpa.s): 1～100,000
Sample size required for each measurement : 250 – 400ml
Viscosity display accuracy: 0.01mpa.s
Measurement error (newtonian liquid): ±3%
Repetitive error (newtonian liquid): ±1.5%
Timing measurement function: standard configuration
Temperature measurement standard configuration
Measurement range display: can automatically display the maximum viscosity of composite rotor and speed of the selected measurement value
Constant temperature component: option (special viscometer constant temperature bath, constant temperature cup, temperature probe, etc.)
Data output interface: standard configuration
Data processing software: option
Working power supply: 110v / 60hz，220v / 50hz
Outline dimension: 300 × 300 × 450(mm)
Main features：
1. measurement data direct LCD screen display does not require two calculations
2. using the latest international microcomputer drive technology, import stepper motor, accurate speed, smooth and reliable
3. the use of advanced switching power supply technology, voltage and frequency range wide, power fluctuations will not affect measurement accuracy
4. level display device is very convenient on the front of the viscometer
5.all ranges, the display accuracy of viscosity value is accurate to two decimal places, that is, 0.01mPa.S.
6. with the function of timing measurement, it is very useful for detecting non Newtonian liquid
7.using small sample adapters, the amount of sample required for each measurement is very small, 18ml.
8. automatic scanning function, the instrument can automatically recommend the best combination of rotor and speed
9.automatically display the maximum range of viscosity that the selected combination can measure
10.with a print interface, you can directly connect to play micro printing machine, print a variety of data
optional data processing software, can record real-time viscosity with time, speed or rotor (shear rate), temperature changes vary, which provides a good method to understand the viscosity and rheological properties of non Newtonian liquids
