Hardness Scale: HV, HK
Test Force: 10-25-50-100-200-300-500-1000gf
Hardness Range: 1HV ~ 3000HV
Test Force Selection: Manually
Implementation of Standards: EN-ISO6507, ASTM E384&E92 JIs
Loading and Unloading Mode: AUTO
Dwelling Time: 0 ~ 60s Adjustable
Turret: AUTO
Micrometer Eyepiece Multiple: 10X
Measure Resolution Ratio: 0.25µm Drum Reading
Objective Magnification: 10X 40X
Total Magnification Times: 100X (Observation) 400X (Measurement)
Measurement Range: 150µm
Optical Channel: Dual Channel / CCD
Filter: Green
Light Source: Halogen Lamp (Brightness Adjustable)
Hardness Resolution Ratio: 0.1 Vickers Unit
Hardness Conversion: Brinell, Rockwell, Surface Rockwell
Max. Height of Test Sample: 90mm
Centerline Depth: 120mm
XY Test Bench Size: 100 x 100mm
XY Test Bench Moving Distance: 25 x 25mm
XY Test Bench Min. Displacement Number: 0.01mm
Operating Temperature: 23 ±5°C
Operating Humidity: <65%
Host Dimension: 530 x 290 x490mm
Net Weight: 40kg
Power Supply: 220V 2A 50-60Hz
