Rated input voltage: AC 110V/220V±10%
Rated output voltage: 0~150V*4CH
Rated output current: 0~2A*4CH
Rated output power: 300W* 4CH
Transformer mode: Switching power supply
Load regulation:
Voltage: ≤ 0.02% + 5mV
Current: ≤ 0.02% + 5mA
Line regulation:
Voltage: ≤ 0.02% + 5mV
Current: ≤ 0.02% + 5mA
Set value resolution:
Voltage: 1mV
Current: 0.1mA
Setting accuracy (25°C ± 5°C):
Voltage: ≤ 0.1% + 8mV
Current: ≤ 0.2% + 2mA
Readback resolution:
Voltage: 1mV
Current: 0.1mA
Readback accuracy(25°C ± 5°C):
Voltage: ≤ 0.1% + 8mV
Current: ≤ 0.2% + 2mA
Ripple:
Voltage: ≤ 10mV(rms)
Current: ≤ 3mA(ms)
Temperature:
Operating environment: 0 to 40°C ≤ 80% R.H
Storage environment: -15 to 70°C ≤ 80% R.H
Interface Standard: RS232
Machine size (WxHxD): 440x90x340
Net weight: 9 kg
Datasheet
Catalog
Features
• List sequence output function 4 in 1 easy to install and occupies a small space
• Each channel is independently adjustable and isolated from each other
• Voltage compensation function ensures accuracy
• Intelligent temperature controlled fan for quieter usage environment
• Voltage and current range setting function
• Button sound on/off function
