Rated input voltage: AC220V/110V±10%
Rated output voltage: 0-15V
Rated output current: 0-15A
Rated output power: 225W
Load regulation rate: Voltage < 0.02% + 12mV, Current <0.2%±1digits
Line regulation: Voltage < 0.02% + 12mV, Current <0.2%±1digits
Display resolution: Voltage 100mV Current < 10A / 10 * mA 10A:100mA
Display accuracy: <= 0.2% + 2 digits (Environment temperature: 23°C ± 5°C)
Ripple: Voltage ≤2mVrms, Current 10mArms
Temperature Coefficient: 300ppm/°C
Max. output voltage: 15.5V plus/minus 0.5 V
Max. output current: 15.1A plus/minus 0.05A
Input voltage: AC 220V / (110V plus/minus 10)% 50Hz/60Hz
Working condition: Temperature 0°C ~40°C, Relative humidity < 80%
Storage condition: Temperature -15°C ~70°C, Relative humidity < 80%
Cooling method: Smart air cooling
Size (mm): 320 * 130 * 160
Net weight kg: 8.4
Gross weight kg: 8.1
Datasheet
Catalog
• Current pre-set without short circuit, namly can set the max output current directly
• Smart fan reduce the working noise
• Spec:30V/3A, 30V/5A, 60V/3A, 30V/10A, 60V/5A, 15V/10A, 15V/15A
• OTP over temperature protection, more comprehensive protection; • Output on/off function
• Fine/coarse tuning
• Input voltage 110V/220V switchable
• The smallest 300W(60V/5A,30V/10A) linear adjustable power supply in industry
