Maxim Integrated MAX2634AXT/V+T Low Noise Amplifiers 315MHz/433MHz Low-Noise Amplifier for Au
Manufacturer: Maxim Integrated Model: MAX2634AXT/V+T - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Gain: 15.5 dB
Technology: Si
Unit Weight: 68.525 mg
Qualification: AEC-Q100
Mounting Style: SMD/SMT
Test Frequency: 315 MHz
NF - Noise Figure: 1.25 dB
Number of Channels: 1 Channel
Operating Frequency: 315 MHz to 433 MHz
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.2 V
Pd - Power Dissipation: 245 mW
Operating Supply Current: 2.5 mA
Operating Supply Voltage: 2.2 V to 5.5 V
P1dB - Compression Point: - 29 dBm
OIP3 - Third Order Intercept: - 16 dBm
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
