Height: 3.96 mm
Length: 9.04 mm
Resolution: 12 bit
Output Type: Current Unbuffered
Unit Weight: 722 mg
Architecture: R-2R
Settling Time: 1 us
Interface Type: Parallel
Mounting Style: SMD/SMT
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 15.75 V
Supply Voltage - Min: 4.75 V
Analog Supply Voltage: 4.75 V to 5.25 V, 11.4 V to 15.75 V
Digital Supply Voltage: 4.75 V to 5.25 V, 11.4 V to 15.75 V
Operating Supply Voltage: 5 V, 12 V, 15 V
INL - Integral Nonlinearity: +/- 0.5 LSB
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
DNL - Differential Nonlinearity: +/- 1 LSB
