Width: 20.3 mm (0.799 in)
Height: 12.2 mm (0.48 in)
Length: 31.8 mm (1.252 in)
Industry: Medical
Dimensions: 31.8 mm x 20.3 mm x 12.2 mm
Unit Weight: 17 g
Output Power: 3 W
Input Voltage: +/- 9 V to +/- 36 V
Mounting Style: Through Hole
Isolation Voltage: 4 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V, 24 V
Output Current-Channel 1: 300 mA
Output Current-Channel 2: 300 mA
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
