Meiji Techno MT-60/TH-2BB Dual Head Back-to-Back Biological Microscope (4X, 10X, 40X, 100X oil)

Eyepieces:

EWF 10x, Field of View 20 mm, diopter adjustment on left eyepiece (Tube 23.2 mm, Tube length 160 mm)

Field of View 22 mm, diopter adjustment on both eyepieces

Viewing Head:

Binocular and Trinocular: 30° inclined tubes

Interpupillary Distance: 48–76 mm

Trinocular ratio: 100:0 / 50:50

Diopter Adjustment: ±5 on 30 mm tube

Tube Rotation System: High position 431 mm, Low position 397 mm

Trinocular port: 23.2 mm

Multi-Head System:

MT-60/MT-61 expandable to 2, 3, or 9 heads for simultaneous observation

Central controller for moving green and red laser beams

Compatible with 30° inclined tube and Plan objectives 4x, 10x, 40x, 100x oil, Infinity corrected IOS

EWF 10x/22 mm eyepiece

Viewing Head:

Binocular head with additional binocular tube, 30° inclined

Interpupillary Distance: 50–75 mm

Diopter Adjustment: ±5 on left tube

Objectives:

Plan IOS 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 oil, Infinity corrected

Anti-fungus and anti-reflection coating

Stage:

Rackless stage: 216 × 150 mm

Integrated mechanical stage: 79 × 52 mm

Focusing:

Coaxial coarse and fine adjustment, 200 divisions

Precision: 1 μm, 0.2 mm per rotation

Total travel: ~24 mm

Rack-stop protection for slides and objectives

Friction adjustment

Illumination:

Diascopic NeoLED Köhler 3W, intensity adjustable

Internal power supply 100–240V (CE)

iCare Sensor: automatic shut-off when observer leaves, energy saving
