Meiji Techno MT-60/TH-3 Three-Headed Biological Microscope (4X, 10X, 40X, 100X)

Eyepieces: EWF 10x/20 mm and EWF 10x/22 mm, diopter adjustment on left or both sides (23.2 mm tube, 160 mm length)

Viewing Head: Three-head (one main, two side), Siedentopf type, 30° inclined tubes

Interpupillary Distance: 50–75 mm, ±5 diopter adjustment

Objectives: Plan IOS 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil (infinity corrected, anti-fungus, anti-reflection coated)

Nosepiece: Quintuple reversed, ball-bearing mechanism

Stage: 216 × 150 mm rackless stage with integrated 79 × 52 mm mechanical stage

Focusing: Coaxial coarse and fine adjustment, 200 graduations, precision 1 µm, 24 mm travel, with rack stop and tension adjustment

Condenser: Abbe N.A. 1.25, height adjustable, slot for optional sliders

Illumination: 3 W NeoLED™ Köhler, built-in 100–240 V AC power supply

Sensor: iCare Sensor – automatically switches off when not in use

SLC System: Smart Light Control

Protection Layer: APL (Antimicrobial Protection Layer)

Cable Storage: CSS – Cable Storage System

Datasheet
