Metrel MD 9010 Digital Multimeter (60.00 mV … 1000 V; 600.0 µA … 10.00 A)

DC Voltage: 6.000 V … 600.0 V / From ±(0.5% of reading + 3 digits) to ±(2.0% of reading + 5 digits)

AC Voltage (50 … 60 Hz): 6.000 V … 600.0 V / ±(1.5% of reading + 5 digits)

DC Current:

400.0 µA / ±(1.5% of reading + 3 digits)

2000 µA / ±(1.2% of reading + 3 digits)

AC Current:

400.0 µA / ±(2.0% of reading + 3 digits)

2000 µA / ±(1.5% of reading + 3 digits)

Diode Test: Open-circuit voltage < 1.6 VDC

Resistance: 600.0 Ω … 6.000 MΩ / From ±(1.0% of reading + 4 digits) to ±(2.0% of reading + 6 digits)

Frequency: 10.00 Hz … 30.00 kHz / ±(0.5% of reading + 4 digits)

Capacitance: 100.0 nF … 2000 µF / ±(3.5% of reading + 6 digits)

Power Supply: 3 V button battery (IEC-CR2032)

Overvoltage Category: CAT III / 300 V; CAT II / 600 V

Dimensions: 113 × 53 × 10.2 mm

Weight: 78 g
