Width: 3.9 mm
Height: 1.25 mm (Min)
Length: 4.9 mm
Shutdown: No Shutdown
Technology: CMOS
Output Type: CMOS, TTL
Supply Type: Single
Unit Weight: 540 mg
Qualification: AEC-Q100
Response Time: 4 us
Mounting Style: SMD/SMT
Comparator Type: General Purpose
Moisture Sensitive: Yes
Number of Channels: 2 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.6 V
Ib - Input Bias Current: 1 pA
Operating Supply Current: 600 nA
Operating Supply Voltage: 3 V, 5 V
Output Current per Channel: 30 mA
Vos - Input Offset Voltage: 7 mV
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
CMRR - Common Mode Rejection Ratio: 70 dB
PSRR - Power Supply Rejection Ratio: 80 dB
