Miljoco PLF4098LY005-SS Pressure Gauge (30" Hg-0-100 psi & bar; 3-2-3%; 1/4" NPT)

Pressure Range: 30" Hg-0-100 psi & bar

Dial Size: 4"

Accuracy: 3-2-3%

Process Port: 1/4" NPT

Mounting: Lower Mount

Tube & Socket: Stainless Steel

Feature: Glycerin Filled

Case: 300 Series Stainless Steel.

Ring: 300 Series Stainless Steel, Bayonet Type With Gasket.

Lens: Acrylic.

Dial: Aluminum, White Finished With Black Markings.

Pointer: Aluminum, Black, Micro-Adjustable.

Movement: Stainless Steel, Rotary Type.

Tube & Socket: 316 Stainless Steel.

Connection: 1/4” Npt Bottom Outlet.

Accuracy: ±1% Full Scale (Asme B40.100 Grade 1A).

Process Temperature: 0 To 140°F (-18 To 60°C).

Ambient Temperature: 0 To 140°F (-18 To 60°C).

See more detail information in the Datasheet
