Control Range: 2% to 100% of Full Scale
Full Scale Flow Range: 5 - 50,000 sccm
Seal Material: Viton, Buna-N, Neoprene, or Kalrez
Analog Connector: 9-pin or 15-pin D-subminiture
Maximum Inlet Pressure: 150 psig
Normal Operating Pressure Differential: 10 to 5000 sccm; 10 to 40 psid
10000 to 20000 sccm; 15 to 40 psid
30000 to 50000 sccm; 25 to 40 psid
Proof Pressure: 1000 psig
Burst Pressure: 1500 psig
Typical Accuracy: ±1% of set point for 20 to 100% Full Scale, ±0.2% of Full Scale for 2 to 20% Full Scale
Repeatability: ±0.3% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: <0.05% of Full Scale/°C
Span Temperature Coefficient: <0.08% of Reading/°C
Inlet Pressure Coefficient: <0.02% of Reading/psi
Typical Settling Time: <750 msec, typical above 5% Full Scale
Warm-up Time: 30 minutes
Operating Temperature: 10°C to 50°C
Storage Humidity: 0 to 95% Relative Humidity, non-condensing
Storage Temperature: -20° to 80°C
Wetted Materials: 316L S.S. VAR, 316 S.S., Elgiloy®, Nickel
Surface Finish: 16µ inch average Ra
Weight: 3 lbs (1.4 kg)
Compliance: CE
For specific range please check the attachment below!
