Full Scale Flow Range: 5 - 50000 sccm Full Scale (N2 equivalent)
Maximum Inlet Pressure: 150 psig
Normal Operating Pressure Differential: 5 to 5000 sccm: 10 to 40 psid
10000 to 20000 sccm: 15 to 40 psid
30000 to 50000 sccm: 25 to 40 psid
Proof Pressure: 1000 psig
Burst Pressure: 1500 psig
Control Range: 2% to 100% of Full Scale
Typical Accuracy: ±1% of set point for 20 to 100% Full Scale, ±0.2% of Full Scale for 2 to 20% Full Scale
Repeatability: ±0.3% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: <0.05% of Full Scale/°C
Span Temperature Coefficient: <0.08% of Reading/°C
Inlet Pressure Coefficient: <0.02% of Reading/psi
Typical Settling Time: <750 msec., typical above 5% Full Scale
Warm-up Time: 30 min
Operating Temperature: 10° to 50°C
Storage Humidity: 0 to 95% Relative Humidity, non-condensing
Storage Temperature: -20° to 80°C
Seal Material: Viton, Buna-N, Neoprene, Kalrez®, or EPDM
Wetted Materials: 316L S.S. VAR, 316 S.S., Elgiloy®, Nickel
Surface Finish: 16µ inch average Ra
Enclosure Rating: IP66
Power Requirements: +15 to +24 VDC @ (<4 watts)
Flow Input Output Signal: 0 to 5 VDC
Analog I/O Connector: 15-pin Type "D" male, 9-pin Type "D" Male
Weight: 3 lbs (1.4 kg)
Compliance: CE
For specific range please check the attachment below!
