Full Scale Flow Range: 5 - 50,000 sccm (N2 equivalent)
Maximum Inlet Pressure: 150 psig
Normal Operating Pressure Differential: 5 to 5000 sccm (10 to 40 psid)
10000 to 20000 sccm (15 to 40 psid)
30000 to 50000 sccm (25 to 40 psid)
Proof Pressure: 1000 psig
Burst Pressure: 1500 psig
Control Range: 2% to 100% of Full Scale
Typical Accuracy: ±1% of set point for 20 to 100% Full Scale
±0.2% of Full Scale for 2 to 20% Full Scale
Repeatability: ±0.3% of Reading
Resolution: 0.1% of Full Scale
Zero Temperature Coefficient: < 0.05% of Full Scale/°C
Span Temperature Coefficient: < 0.08% of Reading/°C
Inlet Pressure Coefficient: < 0.02% of Reading/psi
Typical Settling Time: < 750 msec., typical above 5% Full Scale
Warm-up Time: 30 minutes
Operating Temperature: 10° to 50°C
Storage Humidity: 0 to 95% Relative Humidity, non-condensing
Storage Temperature: -20° to 80°C
Temperature Display: 0 to 100°C
Temperature Accuracy: ±2°C
Temperature Resolution: 0.1°C
Display: 4 digits for value, 4 characters for unit
Valve Seat Material: PTFE (Teflon)
Weight: 3 lbs (1.4 kg)
Compliance: CE
Power Requirements: +15 to +24 VDC @ 350mA max
Analog I/O Connector: 15-pin Type "D" Male, 9 pin Type "D" Male
Flow Input Output Signal: 0 to 5 VDC
For specific range please check the attachment below!
