Swing: 530
Drilling / Tapping capacity
- Mild steel: 40 mm / M25
- Cast iron: 50 mm / M32
Boring capacity mild steel / cast iron: 100 / 110 mm
Spindle stroke auto / manual: 170 / 180 mm
Auto feed number and range: No.3 - 0.08 / 0.16 / 0.26 mm/min
Spindle taper: MT#4
Spindle speed: 60 HZ - 52~1710 rpm
Spindle motor: 1.5 kw / 4/8P
Table size/ RD - SQ: - / 800 x 500 mm
Spindle nose to table surface top: 260~640 mm
Table vertical travels: 380 mm
Base: 870 x 900 mm
Net weight: 800 kgs
Datasheet
