Swing: 530
Drilling / Tapping capacity
- Mild steel: 40 mm / M25
- Cast iorn: 50 mm / M32
Boring capacity mild steel / cast iron: -
Spindle stroke auto / manual: 170 / 180 mm
Auto feed number and range: No.3 - 0.08 / 0.16 / 0.26 mm/min
Spindle taper: MT#4
Spindle speed: 60 HZ- 90~1515 rpm
Spindle motor: 1.5 kw / 4P
Table size/ RD - SQ: 510 mm - 560 x 460 mm
Spindle nose to table surface top: 10~710 mm
Table vertical travels: 520 mm
Base: 460 x 810 mm
Net weight: 550 kgs
Datasheet
