Frequency RangeVHF: 136 – 174 MHz, UHF: 400-470 MHz
Number of Channel : 16 channels
Power Supply Voltage : 7.4 V nominal
Channel Spacing25/12.5 kHz
Battery Life (5-5-90 duty w/battery saver) 1800mAh Li Ion Battery11 hours
IP Rating: IP54
Operating Temperature Range: -13 F to 140 F (-25C to 60 C)
Dimension (HxWxD): 4.3 x 2.3 x 1.4 in (109 x 60 x 37 mm) with 1800 mAh Battery
Weight (Approx.): 270g w/FBN-Z182Li
Receiver Specification
Sensitivity: Analog 12 dB SINAD: 0.20 uV
Adjacent Channel Selectivity: 65/60 dB
Intermodulation60/55 dB
Spurious and Image Rejection: 70 dB
Audio Ouput: 1W @ 16 Ohms (INT)
Hum and Noise: 40 dB
Conducted Spurious Emission: -57 dBm for < 1Ghz
-47 dBm for > 1Ghz
Transmitter specification
Output PowerVHF: 5/1 Watt; UHF: 4/1 Watt
Modulation Limiting±2.5 kHz
Conducted Spurious Emission: -36 dBm for < 1Ghz
-30 dBm for > 1Ghz
FM Hum and Noise: 45/40 Db
Audio Distortion: <3%
Frequency Stability: ±1.5 ppm
