Measuring function: AC load current
CT shape: Round shape
CT Inside diameter: 35mm
Measuring range: 20A/ 200A/ 600A (Auto)
Accuracy:
20A/200A range: ±2.5%rdg ±8dgt
600A range: ±2.5%rdg ±8dgt in 200A ～ 399A
±3.0%rdg ±8dgt in
400A ～ 600A
Resolution:
20A range: 0.01A
200A range: 0.1A
600A range: 1A
Applicable frequency: 50~60Hz
Withstanding voltage: AC 24kV
Operating temp & humidity range: 0℃～40℃, 80%RH or less
Storage temp & humidity range: -10℃～60℃, 80%RH or less
Power supply: AAA(LR03) size battery×3
Dimension / Weight: W66×H215.4×D55mm (Not including the universal joint); Approx 400g (including battery weight)
