Width: 19 mm
Height: 12 mm
Length: 22 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 10 %
Inductance: 23 uH
Application: High Current
Termination: Standard
Unit Weight: 12.700 g
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 8.4 A
Saturation Current: 11 A
Maximum DC Resistance: 12 mOhms
Self Resonant Frequency: 13 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
