Width: 6.8 mm (0.268 in)
Height: 9.8 mm (0.386 in)
Length: 19.5 mm (0.768 in)
Industry: Industrial
Dimensions: 19.5 mm x 6 mm x 10 mm
Application: Industrial
Unit Weight: 2.400 g
Output Power: 1 W
Input Voltage: 21.6 V to 26.4 V
Mounting Style: Through Hole
Isolation Voltage: 1 kV
Number of Outputs: 2 Output
Input Voltage - Max: 26.4 V
Input Voltage - Min: 21.6 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 33 mA
Output Current-Channel 2: 33 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: 0 C
