Data Capture
1D: All major 1D symbologies, including EAN-8, EAN-13, UPC-E, UPC-A, Code 128, UCC/EAN128, I2Of5, ITF-14, ITF-6,Matrix 25, CodaBar, Code 39, Code 93, ISSN, ISBN, Industrial 25, Standard 25,Plessey, Code11, MSI-Plessey, UCC/EAN Composite, GS1 Databar, China Post 25,Code 49, Code 16K.
2D: All major 2D symbologies, including PDF 417, QR Code, Micro QR, Data Matrix, Aztec, Maxicode,Chinese Sensible Code, GM Code, Micro PDF417 Code, Code One.
Image Sensor: 1280 * 800 CMOS
Aiming: Red LED
Illumination: Red LED
Depth of Field EAN 13 (13mil)SR: 55mm-365mm
Depth of Field Code 39 (3.3mil)HD: 50mm-90mm
Depth of Field Code 39 (5mil)SR 70mm-180mm HD: 50mm-105mm
Depth of Field PDF417 (5mil)HD: 45mm-95mm
Depth of Field PDF417 (6.67mil)SR: 55mm-175mm
Depth of Field DataMatrix (6.7mil)HD: 45mm - 75mm
Depth of Field DataMatrix (10mil)SR: 55mm-220mm
Field of View Horizontal: 39°
Field of View Vertical: 24°
Scan Angle Roll: 360°
Scan Angle Pitch: ±55°
Scan Angle Skew: ±55°
Minimal Print Contrast: 25%
Physical
Current @ 5VDC Operating:276.6mA (typical), 332.3mA (max.)
Current @ 5VDC Standby:57.4mA (typical)
Dimensions (mm): 39.5(W)×25.4(D)×20(H)mm (max.)
Input Voltage: 3.3VCD via 12-pin FPC; 5VCD via 5-pin box connector
Interfaces: TTL-232, USB
Material: PC, PMMA
Power Consumption: 1456.5mW (typical)
Power Supply InputDC5V, 1.5A
Power Supply Output: AC100~240V, 50~60Hz
Weight: 11g
