Image Sensor: 1280×800 (megapixel) CMOS
Illumination: White LED
Aiming: Laser
Symbologies
1D:Code 11, Code 128, Code39, GS1-128(UCC/ENA-128), AIM 128, ISBT 128,Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-13, EAN-8, ISSN, ISBN, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, ITF-6, ITF-14, Standard 2 of 5,China Post 25, MSI-Plessey, Plessey, GS1Databar(RSS), Code 49, Code 16K
2D:PDF417, QR Code, Micro QR, Data Matrix, Aztec, Maxi Code, Chinese Sensible Code, GM Code, Micro PDF417, Code One.
OCR:Passport OCR, Chinese ID Card, China Travel Permit OCR
Postal:USPS Postnet, USPS Intelligent Mail, Royal Mail, USPS Planet, KIX Post, Australian Postal
Resolution: ≥3mil
Typical Depth of Field
EAN-13:35mm-580mm (13mil)
Code 39:50mm-250mm (5mil)
PDF 417:40mm-215mm (6.7mil)
Data Matrix:30mm-260mm (10mil)
Scan Angle
Pitch: ±60°, Skew: ±60°, Roll: 360°
Field of View: Horizontal 48°, Vertical 30°
Min Symbol Contrast: 15%
Physical
Interface: RS-232, USB
Operating Voltage: 5VDC±5%
Rated Power Consumption: 1351mW (typical)
Current@5VDC
Operating:271.28mA (typical), 281.39mA (max.)
Idle:129.58mA
Dimensions (L×W×H): 117.5×67.5×144mm
Weight: 140g
Notification: Beep, LED, Vibration
Environmental
Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Storage Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity: 5%~95% (non-condensing)
ESD: ±15 KV (air discharge); ±8 KV (contact discharge)
Drop: 1.5m
Sealing: IP52
Certificates
Certificates & Protection: CE, FCC, RoHS 2.0, IEC62471, IEC60825
