Logic Type: CMOS, TTL
Logic Family: LVC
Logic Function: AND, MUX, NAND, NOR, OR, XNOR, XOR, Buffer, Inverter
Mounting Style: SMD/SMT
Output Current: 50 mA
Output Voltage: 5.5 V
Number of Gates: 1 Gate
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.65 V
Number of Input Lines: 3 Input
Number of Output Lines: 1 Output
Pd - Power Dissipation: 250 mW
Propagation Delay Time: 6.4 ns
Low Level Output Current: 32 mA
High Level Output Current: - 32 mA
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
